Beauway 1500kg Steel Plate Hydraulic Cantilever Tail Lift
PRODUCT PARAMETERS
Description
TAIL LIFT OVERVIEW
Designed for demanding cargo operations, the Beauway 1500kg cantilever tail lift provides a dependable loading solution for commercial trucks, logistics transport vehicles, and distribution fleets. The reinforced steel platform structure delivers excellent durability and structural strength, allowing the lift to safely handle cargo loads up to 1500kg during daily freight and warehouse delivery operations.
In modern freight transportation, efficient loading equipment plays a critical role in improving vehicle turnaround time. Many commercial vehicles rely on cantilever lifts because the structure allows stable lifting while keeping the rear cargo area fully accessible. The Beauway hydraulic truck tail lift operates through a powerful electro-hydraulic system that supports both 12V and 24V vehicle power supplies, ensuring controlled lifting, lowering, and platform tilting during loading procedures.
Equipped with multiple motor options (2.0kW, 2.2kW, and 2.4kW), this cantilever tail lift delivers reliable lifting performance across different cargo handling requirements. The adjustable platform dimensions (height 1600–1800mm and width 1800–2500mm) allow flexible installation on various truck body sizes, making it suitable for logistics fleets, freight transport vehicles, and industrial delivery trucks that require durable truck tail lift systems.
TECHNICAL SPECIFICATIONS
| Parameter | BW-PP15-110 | BW-PP15-130 | BW-PP15-150 |
|---|---|---|---|
| Platform Size | H1600-1800 W1800-2500 (customizable) | H1600-1800 W1800-2500 (customizable) | H1600-1800 W1800-2500 (customizable) |
| Load Capacity | 1500KG | 1500KG | 1500KG |
| Power Supply | 12V/24V | 12V/24V | 12V/24V |
| Working Pressure | 16-18 MPa | 16-18 MPa | 16-18 MPa |
| Lifting Height (mm) | 850-1050 | 950-1250 | 1200-1450 |
| Frame Model | 680 | 750 | 880 |
| Total Weight (kg) | 450KG | 450KG | 450KG |
TAIL LIFT SHOWCASE
FAQs
What Is The Main Purpose Of Tail Lift?
Tail Lift Is Mainly Used To Assist In Loading And Unloading Heavy Or Large Cargo. With The Tail Lift, Operators Can Easily Lift Cargo From The Ground To The Carriage, Or Lower Cargo From The Carriage To The Ground, Greatly Improving Loading And Unloading Efficiency And Reducing Labor.
What Types Of Tail Lifts Are There?
There are several types of tail lifts, including Cantilever Tail Lift, Folding Tail Lift, Retractable Tail Lift, Vertical Tail Lift, Tuckaway Tail Lift, and Three-Section Bumper Tail Lift, designed for different trucks and loading needs.
How To Choose A Suitable Tail Lift?
Vehicle Type: Different Types And Sizes Of Tail Lifts Are Suitable For Different Models.
Loading Requirements: Choose A Tail Lift With Appropriate Load Capacity According To The Weight Of The Cargo.
Frequency Of Use: It Is Recommended To Choose A Tail Lift With Higher Durability For Frequent Use.
Convenience Of Operation: Choose A Tail Lift That Is Simple To Operate And Easy To Maintain.
What Is The General Load Capacity Of A Tail Lift?
The Load Capacity Of A Tail Lift Varies According To The Model And Purpose, Generally Ranging From Several Hundred Kilograms To Several Tons. When Choosing A Tail Lift, Ensure That Its Load Capacity Meets Actual Needs To Ensure Safety And Stability.
Is The Installation And Maintenance Of The Tail Lift Complicated?
The Installation Of The Tail Lift Usually Requires Professional Technicians To Ensure Its Safe And Reliable Working Condition. In Terms Of Maintenance, Regularly Check The Hydraulic System, Electrical System And Mechanical Parts To Ensure Their Normal Operation And Replace Worn Parts In Time.
