Tail Lift
ABOUT TAIL LIFT
TAIL LIFT SYSTEMS ARE WIDELY USED IN TRANSPORT FOR EFFICIENT CARGO LOADING AND UNLOADING OPERATIONS.
WE ARE
- Engineered for reliable lifting performance in daily transport operations
- Designed to improve loading efficiency and reduce manual handling
- Built with durable structural and hydraulic components
- Focused on stable operation and safe cargo handling
- Suitable for various truck and logistics vehicle applications
OUR CLIENTS
We are a trusted truck tail lift manufacturer in China and tail lift supplier for trucks, building long-term B2B partnerships in logistics, commercial vehicles, and loading equipment. Our clients include SF Express, ZTO, Deppon, JD Logistics, Sinotruk, Foton Motor, as well as JAC Motors, XCMG, and Shaanxi Automobile Group.
Our products include truck tail lift systems, hydraulic tail lifts, truck liftgates, and liftgates for trucks, widely used in box trucks and delivery fleets. These systems improve loading efficiency, enhance cargo safety, and increase overall fleet productivity through reliable rear lifting solutions.
As a global truck liftgate supplier in China and experienced tail lift manufacturer, we serve markets including Australia, New Zealand, the Middle East, Southeast Asia, and Europe, providing OEM and customized hydraulic tail lift solutions for commercial fleets and logistics operators worldwide.
TECHNICAL SPECIFICATIONS
| Specification | BW-PP05 Series | BW-PP10 Series | BW-PP15 Series | BW-PP20 Series |
|---|---|---|---|---|
| Carrying Capacity (kg) | 500 kg | 1000 kg | 1500 kg | 2000 kg |
| Compartment Floor Height (mm) | 600-1100 mm | 700-1200 mm | 850-1450 mm | 950-1650 mm |
| Platform Plate Size (mm) | H1600~1800 W1800-2100 mm | H1600-1800 W1800-2500 mm | H1600-1800 W1800-2500 mm | H1600-1800 W1800-2500 mm |
| Spring-to-Rear Distance | ≥580 ~ ≥750 | ≥650 ~ ≥750 | ≥730 ~ ≥930 | ≥800 ~ ≥930 |
| Working Voltage (V) | 12 | 12/24 | 12/24 | 24 |
| Motor Power (kW) | 1.2 | 2.0/2.2/2.4 | 2.2/2.4/2.8 | 2.2/2.4/2.8 |
